Complete External Fuel Tank Relocation Kit Upgrade for 4-Stroke Engines (with GX200/160 Vacuum Sandwich)
$ 82.04
- *NOTE: Fuel Tank Caps supplied may vary in colour between Black and Red.*** Fuel tank relocation kit with external fuel tank. Complete kit – this kit contains everything you need to remove your old small on-board fuel tank on your 4-stroke, and replace it with an external steering upright mounted tank. INCLUDES: 1x External Fuel Pump (vacuum pulse operated) 1x External 9L Fuel Tank Capacity: ~ 9L Dimensions: Bottom – 23cm x 17cm Height – 25cm to bottom of cap Height of retainer button – 18cm Approx. width of steering uprights at button height (18cm) – approx 75mm (min. inside to inside) 1x Fuel Tank mounting bracket 1x Fuel Tank mounting thumbscrew 2.0m Fuel Line 1x Fuel tank spigot for fuel line entry. 1x Fuel Filter 1x Vac pulse sandwich plate [please note silver vac plate in picture for represtation only – black vac plate as pictured below will be supplied] (for tapping vacuum to connect to vac pump) – suits Honda GX200/160, briggs etc where hole spacing/venturi is approx: Dia of holes are 6.8mm (for a 6mm threaded stud) and they are 43mm centre to centre. Bore/Venturi dia is 19.5mm. 1x Vac Pulse Sandwich Gasket Set Relocate and increase the size of your tank easily with this complete kit – no more to buy!
